Tachometer(Contact type ) in bangladesh

Description
Detailed Product Description

Digital Contact Tachometer DT2235A
contact tach:0.5-19,999 rpm,
surface speed:0.05-1,999.9m/min

Digital Contact Tachometer
Model: DT2235A
Shenzhen Sanpo Instrument Co.,Ltd (A1)

Basic function DT2235A General features DT2235A
Display 5 digits white backlight LCD Battery type 3 X 1.5V AA battery
Detector type contact Product dimension 160*72*37mm
Contact tach range 0.5~19,999 RPM Unit weight 170g with battery
Resolution 0.1 RPM (0.5~999.9 RMP) MOQ 50 pcs
1 RPM(over 1,000 RMP) Carton Size 68*32*28cm
Surface speed 0.05~1,999.9 m/min Q'TY / Ctn 20 pcs
Resolution 0.01m/min (0.05~99.99m/min) Gross weight 14 kgs
0.1m/min (over 100m/min) Net weight 10 kgs
Surface length 0.05~99,999 m Package white box & leather case
Battery consumption Aprrox 45mA Testing accessory reflecting tape marks
Sampling time 0.5 sec operation manual & bolt bag
Value function MAX,MIN,Last value contact speed measure fitting
Memory function can store 96s testing value contact rotationla speed fitting

5 digits 18mm (0.6") LCD
Accuracy: ±(0.05%+1 digit)
Sampling Time: 0.5sec(over 120RPM)
Range Select: Auto-Ranging
Memory: Max. value, Min. value, Last value
Test Range: 6MHz Quartz crystal
Power Consumption: Approx 45mA
Time Base: 6MHz Quartz crystal
Time Base Accuracy: 10x10-6(0~50°C)
Measurement:
CONTACT TACH: 0.5~19,999RPM
SURFACE SPEED: 0.05~1,999,9m/min
SURFACE SPEED: 0.2~6,560ft/min
Resolution:
CONTACT TACH:
0.1RPM(0.5~999.9RPM)
1RPM(over 1,000RPM)
SURFACE SPEED:
0.01m/min(0.05~99.99m/min)
0.1m/min(over 100m/min)
SURFACE SPEED:
0.1ft/min(0.1~999.9ft/min)
1ft/min(over 1,000ft/min)
Battery: 4x1.5V AA battery
