SONY BRAVIA 55 inch 4K TV

55 inch X Series BRAVIA 4K LED backlight / 3D TV
Model:
KD-55X8504A
Experience the most immersive home entertainment with our latest 4K*1 LED TV.The KD-55X8504A comes with unique to Sony TRILUMINOS™ Display and 4K X-Reality™ PRO Picture Engine, bringing you richer colours up-scaled to a near 4K picture quality, on any source.
• 4K*1 Resolution (4 times the resolution of a Full HD TV)
• 4K X-Reality™ PRO processing engine to upscale any source instantly
• TRILUMINOS™ Display for bolder and more vivid colors
• One-touch mirroring*2 to share your NFC compatible Xperia™ smartphone's screen on the BRAVIA 4K TV
• Greater control and content enjoyment via TV SideView™
• Life-like 3D viewing experience
HDMI2.0 Upgradable:
The “4K*1 LED TV 65” and 55” X8504A/8500A series will gain the ability to support HDMI Specification Version 2.0 to accommodate 4K/60p *3 content via an internet firmware upgrade through the TV, from the end of 2013.”

*1 3,840 x 2,160 pixels.
*2 The video quality may be degraded due to environmental
interference.
*3 59.94 / 60 Hz




Model

Screen Size 55" (140cm), 16:9

TV System 1 (Digital/Analog): B/G, D/K, I, L, M

Colour System PAL, SECAM, NTSC 3.58, NTSC 4.43

Video Signal 480/60i, 480/60p, 576/50i, 576/50p, 720/50p, 720/60p, 1080/50i, 1080/60i, 3840x2160/24p, 3840x2160/25p, 3840x2160/30p, 4096x2160/24p, (HDMI™ only:720/24p, 720/30p, 1080/24p, 1080/30p), (HDMI™ / Component: 1080/50p, 1080/60p)



Display Resolution 4K(3840x2160)

Video Processing 4K X-Reality PRO

Motionflow™ Motionflow XR 800 Hz (for Philippine Motionflow XR 960 Hz

Backlight Module LED

Deep Color Yes

Intelligent MPEG Noise Reduction Yes (2K only)

MPEG Noise Reduction Yes

Advanced Contrast Enhancer (ACE) Yes

24p True Cinema™ Yes

PhotoTV HD Yes

Viewing Angle 178° (Right/Left), 178° (Up/Down)

Screen Format TV: Full/ Normal/ Wide Zoom/ Zoom/Caption/14:9, PC: Normal/Full1/Full2, 4:3 Default

Picture Mode Vivid, Game-Standard, Game-Original, Graphics, Sports, Animation, Standard,Custom, Photo-Vivid, Photo-Standard, Photo-Original, Photo-Custom, Cinema1, Cinema2

CineMotion/Film Mode/Cinema Drive Yes

3D Comb Filter Yes

3D Active

3D Sync Transmitter Integrated Yes

Simulated 3D Yes(2K-only)


Audio

Sound Mode Standard, Cinema, Sports, Music, Game, Compressed Audio

Sound Enhancer Yes

S-Master Yes

S-Force S-Force Front Surround

Dolby® Dolby® Digital, Dolby®Digital Plus, Dolby® Pulse

Simulated Stereo Yes

Stereo System NICAM/A2

Audio Output Power 10W+10W+10W

Speaker Configuration 2.1ch, Tweeter(20x40mm)x2, Woofer(57mm)x2, Assist Woofer(60mm)


Terminals

HDMI™ Connections 4

USB 2.0 3port

Ethernet Connection 1 (Vertical)

Composite Video Input(s) 2 (1 Rear/1 Rear Hybrid w/Component)

Component Video (Y/Pb/Pr) Input(s) 1 (Rear/Hybrid)

RF Connection Input(s) 1 (Bottom)

Analog Audio Input(s) 2 (Rear)

Digital Audio Output(s) 1(Rear)

Audio Out 1 (Side/Hybrid w/HP)

Headphone Out 1 (Side/Hybrid w/Audio Out)

MHL (Mobile High-Definition Link) Yes


Other Features

BRAVIA Sync Yes

Fast Zapping Yes

USB Play Yes (USB viewer supports FAT16, FAT32, exFAT and NTFS file systems)

DLNA MPEG1/ MPEG2PS/ MPEG2TS/ AVCHD/ MP4Part10/ MP4Part2/ AVI(XVID)/ AVI(MotionJpeg)/ MOV/ WMV/ MKV/ WEBM/ 3GPP/ MP3/ WMA/ LPCM/ JPEG/ MPO

Picture Frame Mode Yes

Scene Select Photo, Music, Cinema, Game, Graphics, Sports, Animation

Parental Control Yes

Clock Yes

Sleep Timer Yes

On/Off Timer Yes

Teletext Yes

PAP (Picture And Picture) PAP(Variable)

OSD Language Afrikaans/ Arabic/ Persian/ English/ French/ Indonesian/ Portuguese/ Russian/ Swahili / Thai/ Vietnamese/ Chinese(Simplified)/ Chinese(Traditional)/ Zulu/ Assamese/ Bengali/ Gujarati/ Hindi/ Kannada/ Malayalam/ Marathi/ Oriya/ Punjabi/ Tamil/ Telugu

TV Guide On Screen / EPG Yes


Network Features

One-Touch Mirroring Yes

Screen Mirroring Yes

TV SideView™ Yes

Wi-Fi Direct Yes

Skype™ Ready Yes


Sony Entertainment Network

Internet Video Yes

Facebook and Twitter Yes


ECO Features

Eco Settings Yes

Dynamic Backlight Control Yes

Backlight Off Mode Yes

Light Sensor Yes

Power Saving Modes Yes


General

Power Requirements AC 110-240V

Power Consumption Approx. 264W

Standby Power Consumption Approx. 0.4W

Dimensions (W x H x D) with Stand Approx. 1259 x 770 x 405 mm

Dimensions (W x H x D) without Stand Approx. 1259 x 740 x 59 mm

Weight with Stand Approx. 28.2 Kg

Weight without Stand Approx. 26.8 Kg


Supplied Accessories

One-touch Remote Control RMF-ED003

Remote Control RM-GD026

Batteries R03

3D Glasses TDG-BT400A x4

3D Sync Transmitter Yes

AC Power Cord Euro 2 Pin, Pig-tail

Screws Yes

Operating Instructions GB,CS,FR,VN,AR,PR,RU,ID

Table Top Stand separate (assembly required)
