Power On Electronics Bd 650 VA Servo Stabilizer(2 year)

Technical Parameters

Phase Single Phase Three Phase
Capacity 650VA ~ 15KVA 3KVA - 2000KVA
Input Voltage Range 140V ~ 270V, 120V ~ 280V, 100V ~ 280V 300V ~ 460V/250V~460V/ 220V~460V
Output Voltage Range 220V / 230V / 240V AC 380V / 400V / 415V / 440V / 460V
Frequency 50Hz 50Hz
Control System By Servo motor Control / Relay Combined or Individual Phase control by Servo motor
Protection Over voltage, Under voltage, Over load, Short circuit, Surge, Spike, etc Over voltage, Under voltage, Over load, Short circuit, Surge, Spike, etc Protection, Phase Sequence Protection and Phase Missing.
Monitoring System LCD/LED Display / Digital Display LCD/LED Display
Correction Accuracy ± 1% / ± 3% / ± 8% ±1% /±3%
Correction Speed 30 to 50V/Sec.
Cooling System Natural Air / Air Forced / Oil immersed
Waveform Distortion Negligible
Transient Suppression Upto 800V Peak
Load Power Factor Effect Nil
Environment Condition 40C~600C
Duty Cycle 95% Continuous
Humidity Maximum 98%
Over load Capacity 100% for 15 Sec.
Note: Manufacturer reserves the right to change the design and specification at my time without any prior notice.

01. Fully automatic and Electronic Control
02. Automatic circuit with delay and reset function
03. Protection against sag, surge, spike and 440 volt
04.compact in size, quick and quite operation
05. EMI and RFI noise suppression
06. Clear LTE indication for efficent operation
07. Used all ISO-9002 certified components
08. Specially can be used in low voltage application
09. Protection against over and under voltage
