tharmaltake smart power 550W Power sup

tharmaltake smart power 550W Power sup

US Product Code: SP-550PCBUS
Australia Product Code:: SP-550PCBAU
Type Intel ATX 12V 2.3
Max. Output Capacity 550W
Peak Output Capacity 660W
Color Black
Dimension (H x W x D) 86mm x 150mm x 140mm
PFC （Power Factor Correction） Active PFC
Power Good Signal 100-500 msec
Hold Up Time 16msec (minimum) @ 80% of full load at 115Vac/ 230Vac input.
Input current 8A
Input Frequency Range 47 Hz - 63 Hz
Input Voltage 100 Vac- 240 Vac
Operating Temperature 0℃ to +40℃
Operating Humidity 20% to 90%,non-condensing
Storage Temperature -20 ℃ to +70 ℃
Storage Humidity 5% to 95%, non-condensing
Cooling System 120mm Fan: 1800 R.P.M. ± 10%
Efficiency 82-88% efficiency @ 20-100% load
MTBF 100,000 hrs minimum
Safety Approval UL/CUL/TUV/CE/FCC and BSMI
Protection OVP/UVP/OCP/OPP/SCP
Connector 24 Pin x 1
CPU 4+4 Pin x 1
PCI-e 6+2 Pin x 2
SATA x 6
4 Pin Peripheral x 4
4 Pin Floppy x 1
Max Output Current +3.3V: 24A
+5V: 15A
+12V: 42A
-12V: 0.5A
+5VSB: 3.0A
Max Output Power +3.3V & +5V: 105W
+12V: 504W
-12V: 6.0W
+5VSB: 15W
