Weinview Monitor 7" HMI TK6070IP

Specification
Monitor 7 "TFT

Resolution (WxH dots) 800 x 480

Display Brightness (cd/m2) 350

Contrast 500:1

Backlight type LED

Backlight Life > 30,000 hours

Display colors 65536

Touch Panel Type 4 -wire analog resistive

Touch Accuracy Active Area Length (X) ± 2%, Width (Y) ± 2%

Memory Flash memory (MB) 128

DRAM (MB) 64

Processor 32Bit RISC CPU 400MHz

Communication port Mini USB download port USB 2.0 x 1 COM port

COM1 RS-232, COM2 RS-485 2W/4W

Calendar: Built-in

Power supply Input Power 24 ± 20% VDC

Power Consumption 350mA @ 24V

Isolated power supply unit No

Pressure 500VAC (1 min.)

Insulation resistance More than 50MW at 500VDC

Earthquake 10 to 25Hz (X, Y, Z direction 2G30 minutes )

Shell material Industrial Plastics

Dimensions WxHxD 200.4 x 146.5 x 34mm

Hole size (mm) 192 x 138

Weight (kg) Approximately 0.52kg

Operating environment

Protection class IP65 front panel protection

Storage temperature -20 ° ~ 60 ° C (-4 ° ~ 140 ° F)

Ambient temperature 0 ° ~ 50 ° C (32 ° ~ 122 ° F)

Using ambient humidity 10% ~ 90% RH ( non-condensing )

CE certification EN55022: 2010, EN55024: 2010, EN61000-3-2: 2006 + A2: 2009, EN6100-3-3: 2008, AS / NZS CISPR22: 2009 + A1: 2010

Using Software Simplified Chinese version is limited EB8000 V4.65.06 or later use
