Zebra ZM600 Label printer

Product Description

Zebra ZM600 Thermal Label Printers includes additional productivity-enhancing features and
modern, flexible network connectivity for easy system integration in most manufacturing,
warehousing and business applications.This industrial/commercial workhorse also delivers
efficient 6-inch-wide labeling thanks to its quick throughput and 10 inches-per-second print
speed. Built RFID Ready and offering a multitude of options, the ZM600 is upgradeable to
grow with changing needs.Plus, design enhancements make this new-generation Z Series
printer even easier to operate, load, and maintain.


S TA N DA R D F E AT U R E S
Print methods: Thermal transfer or direct thermal
Construction: Die-cast aluminum base, frameand printhead mechanism
Metal media cover with large clear window
Element Energy Equalizer™ (E3®) for superior print quality
Auto-calibration
Real-time clock
Auto-ranging (90–265 VAC) power supply
Color-coded operator cues
Multi-language control panel with back-lit
240 x 128 pixel display

P R I N T E R S P E C I F I C AT I O N S
Resolution
203 dpi/8 dots per mm; 300 dpi/12 dots per mm; 600 dpi/24 dots per mm (ZM400 only)
Memory
Standard: 8 MB Flash, 16 MB DRAM
Optional: Factory Installed 64 MB Flash
Print Width
ZM400: 4.09"/104 mm
ZM600: 6.6"/168 mm
Print Length
ZM400: with 203 dpi: 157"/3,988 mm; with
300 dpi 73"/1,854 mm; with 600 dpi 39"/991 mm
ZM600: with 203 dpi: 102"/2,590 mm; with
300 dpi 45"/1,143 mm
Print Speed
203 dpi: 10"/254 mm per second;
300 dpi: 8"/203 mm per second;
600 dpi: 4"/102 mm per second
Media Sensors
Fixed reflective sensor
Adjustable transmissive sensor

R I B B O N C H A R A C T E R I S T I C S
Outside diameter
3.2"/81.3 mm
Standard length
984'/300 m or 1476'/450 m
Ratio
3:1 media roll to ribbon.
Ribbon must be at least as wide as media
Width
2.00"/51 mm to 4.33"/110 mm
Ribbon setup
Ribbon wound ink-side out (ribbon wound ink-side in can be used with optional ribbon spindle)
Core I.D.
1.0"/25.4 mm

O P T I O N S A N D A C C E S S O R I E S
Factory installed 64 MB Flash memory option
Cutter with catch tray
Peel—a front mount, passive peel option with no liner take-up
Liner take-up (works with peel option)—full roll liner take-up spindle (fits standard base, ZM400 only)
Rewind—internally rewinds full label roll on 3" core(comes with taller, non-standard printer base)
RS-422/485 serial port adapter
Optional ribbon spindle to support ribbon wound ink-side in (ZM400 only)
