ESONIC, H61 motherboard , 1155 socket ,DDR 3

we are 11 years manufacturer of computer hardware. we export our product with high quality and competitive price,



CPU(Processor)



Intel® Socket 1155 Core™ i7/Core™ i5/Core™ i3 Processors



Supports Intel® Dynamic Speed Technology



Supports Intel® 32 nm CPU



Chipset



Intel® H61(B3)



Memory



Support Dual channel DDR3 1333/1066 SDRAM (8GB Max)



2 * DDR3 DIMMs (240 pin/ 1.5V)



Slots



- 1 * PCI Express x16 Slot



- 1 * PCI Express x1 Slot



Storage



- 4* Serial ATA 2.0 devices



Internal I/O Connectors



- 1 * 24-pin ATX Power Connetor



- 1 * 4-pin ATX 12V Power Connetor



- 2 * USB connector support additional 4 USB ports



- 1 * LPC_DEBUG connector



- 1 * Front panel audio connector



- 1 * System Panel connector



Back Panel I/O Ports



- 1 * PS/2 Mouse/Keyboard



- 1 * VGA



- 1 * COM



- 4 * USB 2.0 / 1.1



- 1 * RJ45(LAN) Port



- 1 * 3 Audio jacks



BIOS



EFI BIOS



LAN



On board Realtek 8105E 1000M LAN, Compliance with PCI 2.2



Audio



Chip integrated by Realtek ALC662, Supports 5.1-channel audio-out



Form Factor

- Micro ATX - 211*168 mm
