AHD ST-AHD778-1M CCTV Camera

Model: ST-AHD778-1M
Image Sensor: IMX238+2431H
Board Specification
1Megapixe ,720P 30fps , IR CUT,DWDR, 3D
TV System: PAL/NTSC
Image Resolution: 1280*960
Horizontal Resolution: 1MP
SYNC.: Internal

Video Out: 1.0Vp-p Composite Signal (75ohm)
Minimum illuminator: 0 Lux (Infrared Light Open)
Gama adjust: 0.45
Electric Shutter
PAL:1/50s-1/100000s: NTSC:1/60s-1/100000s
S/N Ratio: 58dB(min)(AGC closed)
Lens: Built-in 3.6 mm Board Lens (6mm is optional)
Leds: 24 pcs* ￠5mm IR-LED
IR Range: 20M
Cable built in bracket
DNR: Yes
AUTO
AGC: AUTO
BLC: ON/OFF
Day/Night: Auto、Ext
OSD: Optional
Power Input: DC12V±1V
Operation Temperature: Temperature -10℃～+75℃,Humidity less than 85%RH
OSD Language: Chinese EnglisH
Waterproof Level:IP66
Weight: 0.5KG
Dimension: 86(W) x60(H) x55(D)mm
Video Output: 1.0Vp-p,75Ω
