ZKTeco F-18 Time Attandence

Products Brand: ZKTeco
Products Model: F-18-ID


Reliable, durable and highly accurate ZK fingerprint sensor with ver. 10 algorithm provides less than 1.5 second user recognition. Works without computer. Complete setup and programming can be done via keypads and embedded firmware. Graphical user interface on a 3.5 inch TFT display for rich user experience. Audio-Visual Indication for acceptance and rejection of valid/invalid fingerprints. Relay outputs for electric lock and alarm. Inputs for door status sensor and exit switch. Supports multiple time zones and personnel groups for programming valid entry zones. The alarm will be triggered when the tamper switch is activated. Wigand output for connecting to access control panel and Ethernet port for fast and reliable communication with the computer.
Can store up to 1500 templates and 30000 transactions. The data can be backed up to a USB flash drive and can also be transferred to another reader in the absence of computer connectivity. Internal Proximity Card or Mifare Card reader allows dual factor authentication for access control.
 

Features
• Three different kinds of interface style, including common, matrix and magic styles
• Reliable, durable and highly accurate ZK infrared detection fingerprint sensor with version 10.0 fingerprint algorithm
• Less than 1 second user recognition
• Stores 1500 fingerprint templates and 30,000 transactions
• Reads fingerprint and/or RFID cards.
• Built-in Serial and Ethernet ports
• Built-in Wigand input/output port for connection to third part access control panels
• Built-in USB port allows for manual data transfer
• Audio-Visual indication for acceptance and rejection of valid/invalid fingers
• Tamper switch and alarm contacts

Specification
Fingerprint 1500
Transactions 30,000
Display
Color 7″ TFT LCD display
Power
Power Supply 12V DC, 3A
Dimensions
Length 5.8″ (183 mm)
Width 2.5” (80 mm)
Depth 1.3” (42 mm)
Optional Function
Card ID
Card Mifare
Communication
Communication RS485
Communication TCP/IP
Communication USB-Host
Wiegand Signal
Signal Input
Signal Output
Environment
Operating Temperature 32-113 F (0-45 C)
Operating Humidity 20% to 80%
Packaging
Dimensions 3 1/2” x 9 1/4” x 3 1/2”
Weight 3 lbs (48 ozs.)
