Digital Insulation/Continuity Tester in Bangladesh Kyoritsu

Digital Insulation/Continuity Tester in Bangladesh Kyoritsu 3005A
Brand: Kyoritsu
Model: 3005A
Made in Japan
Price: BDT 27,000/-

Kyoritsu 3005A Digital Insulation / Continuity Tester
The Kyoritsu 3005A Digital Insulation and Continuity Tester uses a bargraph to display insulation resistance and displays the value of AC voltage along with a flashing symbol.

Bargraph to display insulation resistance.
Displays the value of external AC voltage along with flashing symbol.
Auto null function to automatically subtract the test lead resistance before displaying the real continuity resistance value.
Live circuit warning beeper.
Releasing the test button automatically discharges the charges stored in the circuit under test.
200mA continuity measuring current to IEC 61557.
Minimum 1mA current on insulation tests to IEC 61557.

Specification:
Insulation Resistance
Test Voltage : 250V/500V/1000V
Measuring Ranges(Mid-scale Value) : 20MΩ/200MΩ/2000MΩ
Output Voltage on open circuit : Rated test voltage+20%, -0%
Nominal Current : 1mA DC min.
Output ShortCircuit Current : 1.5 mA DC approx.
