8 port modem in motijheel

Specifications
1. wavecom q2403a gsm/gprs modem module
2.8 sim card slot
3.free sms software
4.wavecom modem
5.AT command
1. wavecom q2403a gsm/gprs modem module
2.8 sim card slot
3.free sms software
4.can send 4800 pcs SMS an hour
5.AT command


Highlight
1>High-speed bulk sms sending ,each port can send 600 pcs of sms within 1 hour.
2>Brand new first hand modules.Wavecom ,Cinterion,Qualcomm chipsets available
3>Support IMEI change with software,easier to operate,better user experience.
4>Adaptable to all open AT commands,keep working under status of " Hardware"
5>Internal adapter to assure stable voltage & excellent working environment


Key Feature:
1.Just like 8 single-channel equipments work at the same time
2.insert 8 SIM cards(big or small)
3.connection with the computer through a data line be integrated with Serial 8
4.Each channel with separate power switch
5.Each individual module be demolished
6.industrial chassis, elegant shell
7.GSM frequency: 900/1800 MHZ
8.8 SIM card(big/small) slots
9.Wireless access to interne
10.Comply with GSM phase2 standard
11.Dual-band/Quad-band(optional)
12.RS-232/USB interface(optional)
13.8 SIM Card supported (Big/Small)
14.Optional data,voice function
15.send and receive English SMS in bulk

Basic Feature:
-Asynchronous, transparent or non-transparent, to a maximum 14400 bits / s
-Baud Rate : 300-115200 bits / s
-Automatic baud rate: from 2400 to 19200 bits / s
-Fax support three
-Switched voice and fax
-V.42, V.42bis
-GPRS compatible
-WAP compatible
-SMA Antenna Interface
-SIM Card Outlet
-Power connector
-RS-232, the Mini-DB-9 connector
-AT command control ( GSM 07.07 and 07.05)

Application:
-Large shopping malls, supermarkets
-Professional market, large wholesalers
-Large hotels, large-scale entertainment
-Large agencies
-Transport, logistics industry
-Large enterprises, and institutions
-Large hospitals, large bookstore
-Newspaper, television and radio station
-Oil Company ( other chain business model)
-Government agencies or large township

Hardware Feature:
-Support dual-band GSM: 900/ 1800 MHz
-Meet the ETSI GSM 2 + standards
-Class 4 ( 2W @ 900 MHz) Class 5 ( 1W @ 1800 MHz)
-5 -24 VDC power supply (which be directly connected to the nickel- metal hydride or lithium batteries)
-Operating Temperature: -20 ° C - + 55 ° C
-Storage temperature: -25 ° C - + 70 ° C
-Size: standard 1U chassis
