AVTECH DG-103 AP 2MP MADE IN TAIWAN

Product Description

> 1/2.7” CMOS Sensor

>> 1080P video output

>> Low light sensitivity of 0.1 Lux / F1.8, 0Lux (IR LED ON)

>> Day and night 24-hour surveillance with IR effective distance up to 20 meters

>> Camera parameters adjustable when used with AVTECH HD CCTV DVR
MODEL: |
AVT103A
Pick-up Element : | 1/ 2.7” CMOS image sensor
Number of Pixels: | 1930(H) x 1088(V)
Video Frame Rate: | 1080P@30fps / 1080P@25fps
Min. Illumination: | 0.1 Lux / F1.8, 0 Lux (IR LED ON)
S/N Ratio: | More than 48dB (AGC OFF)
Shutter Speed : | 1/30 (1/25) sec ~ 1/720000 (1/600000) sec
Lens: | f3.6mm / F1.8
Lens Angle : | 96° (Horizontal) / 50° (Vertical) / 116° (Diagonal)
IR LED: | 30 units
IR Effective Distance: | Up to 20 meters
IR Shift : | YES
IRIS Mode : | AES
White Balance: | ATW
AGC : | Auto
WDR: | YES (120dB)
External alarm I/O: | YES (1 input / 1 output)
IP Rating: | IP66
OperatingTemperature: |
-25 ~°C50°C
Power Source (±10%): | DC12V / .5A
Current Consumption (±10%) | 200mA
=====================================
