Wood CNC Router

Single Head Wood CNC Router

Applicable Scope：
Classical mahogany furniture, white wood European furniture, carved antique furniture,
wall hollow, solid wood doors, craft doors, Paintfree doors, cabinet doors, craft windows,
variety of tables, sofas, panel furniture, advertising signs, sign making, acrylic cutting,
blister light boxes, curtain walls, aluminum, copper, composite board and other non-ferrous metals.

Performance Features：
1. Imported linear square guide rails, high loading capacity, smooth operation,
high precision, and long life.
2. Imported high precision ball screws, with high-precision when cut.
3. Equipped with automatic lubrication system, centralized lubrication. Reduce
customer maintenance workload, greatly extend the rail life.
4. Adopt famous brand frequency water-cooling spindle, great performance, big torque, high efficiency.
5. Using quality spindle motor and driver, Y-axis dual-motor drive, with faster speed and better stability.
6. Compatible with any advanced CAD/CAM software, such as Type3/ ArtCAM/
CAXA/ UG / pro-e/ Mastercam/ JD/ Wentai, etc..

Optional Parts:
1. Japan imported servo motor (Panasonic, Yaskawa),
Taiwan imported servo motor, or servo motors made in China
2. The number of spindle motor is optional as per your special requirement.
3. The machine size can be customized
4. Vacuum tabletop, dust collector

Technical Parameters:
Model
1325 （Can be customized as your needs）
Working Stoke
1300mm*2500mm
Feeding Height
160mm-250mm
Max Motion Speed
20m/min
Max Processing Speed
10m/min
Spindle Power
2.2KW ~ 9KW frequency water-cooling spindle
（Air-cooling motor, or Italy imported HSD/ELTE/ Colombia motor is optional）
Spindle Rotational Speed
6000 ~ 24000 rpm/min
Working Voltage
AC220V/50Hz or AC380V/50Hz
Engraving Tool
￠3.175/ 4/ 6/ 12.7mm
Dictate Format
G code/ HPGL
Positioning Accuracy
±0.05mm
Repeatability
±0.02mm
Controlling System
NC Studio
