CISCO881-Sec -K9

Flash Memory
Installed Size: 256 MB

Max Supported Size: 256 MB

Networking

Compliant Standards: IEEE 802.1D , IEEE 802.1Q

Connectivity Technology: Wired

Data Link Protocol: Ethernet , Fast Ethernet

Features: Access Control List (ACL) support , Auto-uplink (auto MDI/MDI-X) , Class of Service (CoS) , Class-Based Weighted Fair Queuing (CBWFQ) , DHCP client , DHCP relay , DHCP server , DNS proxy , Fanless , Low-latency queuing (LLQ) , MAC address filtering , NAT support , Quality of Service (QoS) , Spanning Tree Protocol (STP) support , Weighted Fair Queuing (WFQ)

Form Factor: Desktop

Integrated Switch: 4-port switch

Key Features: USB port

Network Transport Protocol: DHCP , L2TP

Remote Management Protocol: CLI , HTTP , HTTPS , SNMP 3 , SSH , Telnet

Routing Protocol: GRE , HSRP , Policy-based routing (PBR) , RIP-1 , RIP-2 , VRRP

Status Indicators: Port status , Power

Type: Router

WAN Ports Qty: 1
________________________________________

RAM

Installed Size: 256 MB

Max Supported Size: 768 MB

Service & Support

Last date to receive service support July 31, 2019
________________________________________

Capacity


Type: IPSec VPN tunnels

Value: 20
________________________________________

Dimensions & Weight


Depth: 9.8 in

Height: 1.7 in

Weight: 5.51 lbs

Width: 12.8 in
________________________________________

Environmental Parameters


Humidity Range Operating: 10 - 85% (non-condensing)

Max Operating Temperature: 104 °F

Min Operating Temperature: 32 °F
________________________________________

Header


Brand: Cisco

Compatibility: PC

Manufacturer: Cisco Systems

Model: 881 Ethernet Security

Packaged Quantity: 1

Product Line: Cisco
________________________________________

Interface Provided


Connector Type: RJ-45

Interface: Ethernet 10Base-T/100Base-TX

Qty: 4

Type: LAN

________________________________________ ________________________________________ ________________________________________

Interface: Console

Qty: 1

Type: Management

________________________________________ ________________________________________ ________________________________________

Type: WAN

________________________________________ ________________________________________ ________________________________________

Connector Type: 4 pin USB Type A

Type: USB
________________________________________

Miscellaneous


Authentication Method: RADIUS , TACACS+

Color Category: Gray

Compliant Standards: CISPR 22 , CISPR 24 , EN 300386 , EN 60555-2 , EN 61000-3-2 , EN 61000-3-3 , EN 61000-6-1 , EN50082-1 , EN55022 Class B , EN55024 , FCC CFR47 Part 15 , FCC CFR47 Part 15 B , ICES-003 , KN22 , VCCI V-3

Encryption Algorithm: 128-bit AES , 192-bit AES , 256-bit AES , DES , PKI , Triple DES
________________________________________

Modem


Type: None
________________________________________

OS Provided


Type: Cisco IOS Advanced Security
________________________________________

Power Device


Frequency Required: 50/60 Hz

Nominal Voltage: AC 120/230 V

Power Provided: 60 Watt

Type: External power adapter with switch
________________________________________

Service



________________________________________
