Suprema || BioEntry Plus Access Control Device.

World-Renowned Suprema Fingerprint Technology

The Powerful,yet sophisticated Suprema fingerprint
algorithm forms the core of every BioEntry Plus, making it
a truly secure biometric access control device.
With unheralded speed and accuracy, Suprema
algorithm has been proven as the world’s best.

Specification
Main Biometric Fingerprint
IP Rating -
RF Options BEPL-OC 125 KHz
BEPM-OC 13.56MHz
MIFARE,MIFARE Plus DESFire/EV1 (CSN)
BEPH-OC 125kHz HID Prox
BEPI-OC 13.56MHz
FeliCa, iCLASS SR
BEPI(FE)-OC FeliCa
Multi-Controller Yes
Capacity Max. User (1:1) 5,000
Max. User (1:N) 5,000
Max. Template (1:1) 10,000
*two templates per finger
Max. Template (1:N) 10,000
*two templates per finger
Max. Text Log 50,000
Max. Image Log -
Interface WiFi -
TCP/IP Yes
RS-485 1ch Host or 1ch Slave
(Selectable)
RS-232 -
Wiegand 1ch In or 1ch Out
(Selectable)
Input 2 Inputs
Relay 1 Relay
USB -
SD Card Slot -
Hardware CPU 533MHz DSP
Memory 8MB RAM + 8MB Flash
LCD -
LED Indicator Multi-Color
Sound Multi-tone Buzzer
Operating Temp. -20° to 50°C
Tamper Yes
Power 12VDC
PoE -
Dimensions 50 x 160 x 37 (WxHxD mm)
Certificates CE, FCC, KC, RoHS
Compatibility BioStar 1.x Yes
BioStar 2 Yes
