Suprema || BioLite Net Access Control Device.

Specification
Main Biometric Fingerprint
IP Rating IP65
RF Options BLR-OC 125 KHz EM
BLN-OC 13.45Mhz MIFARE
MIFARE Plus, DESFire/EV1 (CSN)
Multi-Controller Yes
Capacity Max. User (1:1) 5,000
Max. User (1:N) 5,000
Max. Template (1:1) 10,000
*two templates per finger
Max. Template (1:N) 10,000
*two templates per finger
Max. Text Log 50,000
Max. Image Log -
Interface WiFi -
TCP/IP Yes
RS-485 1ch Host or 1ch Slave
(Selectable)
RS-232 -
Wiegand 1ch In or 1ch Out
(Selectable)
Input 2 Inputs
Relay 1 Relay
USB -
SD Card Slot -
Hardware CPU 533MHz DSP
Memory 16MB RAM + 8MB Flash
LCD 128x64 Graphic LCD
(Monochrome)
LED Indicator Multi-Color
Sound Multi-tone Buzzer
Operating Temp. -20° to 50°C
Tamper Yes
Power 12VDC
PoE -
Dimensions 60 x 185 x 40 (WxHxD mm)
Certificates CE, FCC, KC, RoHS
Compatibility BioStar 1.x Yes
BioStar 2 Yes
