Nikon Digital SLR Camera D5200

Type
Type

Single-lens reflex digital camera
Lens mount

Nikon F mount (with AF contacts)
Effective angle of view

Nikon DX format; focal length equivalent to approx. 1.5x that of lenses with FX-format angle of view
Effective pixels
Effective pixels

24.1 million
Image sensor
Image sensor

23.5 x 15.6 mm CMOS sensor
Total pixels

24.71 million
Dust-reduction system

Image sensor cleaning, Airflow Control System, Image Dust Off reference data (optional Capture NX 2 software required)
Storage
Image size (pixels)


6000 x 4000 [L]
4496 x 3000 [M]
2992 x 2000 [S]

File format


NEF (RAW): 14 bit, compressed
JPEG: JPEG-Baseline compliant with fine (approx. 1:4), normal (approx. 1:8) or basic (approx. 1:16) compression
NEF (RAW)+JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats

Picture Control System

Standard, Neutral, Vivid, Monochrome, Portrait, Landscape; selected Picture Control can be modified; storage for custom Picture Controls
Media

SD (Secure Digital) and UHS-I compliant SDHC and SDXC memory cards
File system

DCF (Design Rule for Camera File System) 2.0, DPOF (Digital Print Order Format), Exif (Exchangeable Image File Format for Digital Still Cameras) 2.3, PictBridge
Viewfinder
Viewfinder

Eye-level pentamirror single-lens reflex viewfinder
Frame coverage

Approx. 95% horizontal and 95% vertical
Magnification

Approx. 0.78x (50 mm f/1.4 lens at infinity, -1.0 m-1)
Eyepoint

17.9 mm (-1.0 m-1; from center surface of viewfinder eyepiece lens)
Diopter adjustment

-1.7 to +0.7 m-1
Focusing screen

Type B BriteView Clear Matte Mark VII screen
Reflex mirror

Quick return
Lens aperture

Instant return, electronically controlled
Lens
Compatible lenses

Autofocus is available with AF-S and AF-I lenses; autofocus is not available with other type G and D lenses, AF lenses (IX NIKKOR and lenses for the F3AF are not supported), and AI-P lenses; non-CPU lenses can be used in mode , but the camera exposure meter will not function
The electronic rangefinder can be used with lenses that have a maximum aperture of f/5.6 or faster
