Solar Street Light Controller

Street Light Controller
-------------------------------
• IP68，Strong and durable aluminum case
• 12V system voltage
• Working time during night selection
• LED status display
• Four stage charge way: fast, boost, equalization, float
• Full automatic electronic protect function

Model : Star series 06
Max solar & load current : 6A
System voltge : 12V
Fast voltge : 14.0V (25℃)
Boost voltage : 14.5V (25℃)
Equalization voltage : 14.8V (25℃)
Float voltage : 13.7V (25℃)
Load disconnect voltage : 11.2~11.8V
Load reconnect voltage : 12.5V
Over voltage protection : 15.5V
Day/Night threshold : 5V
Working time during night : DUSK-to-DAWN，6，8，10，12Hours （Programmable）
Battery type : Liquid
Temperature compensation : -4.17mV/K per cell (boost, equalization), -3.33mV/K per cell (float)
Max solar voltage : 30V
Max battery voltage : 25V
Dimensions/Weight : 85x40x20mm/105g
Cable lenth : 120mm/80mm
Wire size : 1.5mm²
Own consumption : 4mA
Ambient temperature : -40~+60℃
Degree of protection : IP68
Max altitude : 4000m
