Concrete Mixer Machine

Concrete Mixer

Mini Concrete Mixer

Model: TKMM 3 1/2 T (A)/.......
Brand: TOKU / Robin / AmoyTec / JINYAO
Origin: Japan / Malaysia / China
Capacity Unmixed: 105 lit (3.5 cu.ft.)
Capacity Mixed: 75 lit (2.5 cu.ft.)
Engine: Robin EY20D or Honda G200 or Honda GX160 or equivalent
Engine Type: Air-cooled Gasoline
Rated Output (hp/rpm): 3.5/3600
Starting System: Recoil
Warranty: One Year.

Manual Fed Concrete Mixer

Model: TK7TMS/......
Brand: TOKU / Robin / AmoyTec / JINYAO
Origin: Japan / Malaysia / China
Mixing Drum: Using heavy cast iron with mill steel pot and blade-individually renewable.
Capacity Unmixed: 10 cu.ft. or 300 litres
Capacity Mixed: 7 cu.ft. or 210 litres.
Loading Height: 37 in. or 940mm
Drum Opening: 21 in. or 533m
Transmission: Drive-unit- by roller chain and sprocket.
From driving shaft to drum- by level gear and roller type bearings.
Chassis Channels: Rigid fabricated from mild steel channels, plates and angles.
Wheels: Steel wheels are fitted in front and rear.
Discharge: Discharge height is 16 in. or 406mm.
Tipping position is controlled by a handwheel and can be fixed at various mixing positions.
Prime Mover: 5 hp Single cylinder air-cooled diesel engine.
Warranty: One Year.

Contact:

Md. Khalid Hossain
Asst. Manager (Business Development)
Cell: +88 01819003164
Email: [email protected]

FIMEXT CORPORATION (PVT.) LTD.
37, Avenue 01, Block B, Mirpur 11, Dhaka-1216
Tel: +88 04478022223, Fax: +88 029014816
Mobile: +88 01712830435, +88 01911673247
Email: [email protected]
Web: www.fimextbd.com

HOT LINE: +88 01819003162, +88 01819003164
