Model year 2017
Dimensions and Weight
Screen Size (inch, measured diagonally) 43" (42.5")
Screen Size (cm, measured diagonally) 108.0 cm
Dimension of TV without Stand (W x H x D) Approx. 964x571x70 mm
Dimension of TV with Stand (W x H x D) Approx. 964x619x236 mm
Dimension of TV with Floor Stand (W x H x D) -
Dimension of Package Carton (W x H x D) Approx. 1062 x 668 x 158 mm
Stand Width Approx. 620 mm
VESA® Hole Pitch(W x H) 100x200 mm
Weight of TV without Stand Approx. 9.1 kg
Weight of TV with Stand Approx. 9.7 kg
Weight of TV with Floor Stand -
Weight of Package Carton (Gross) Approx. 14 kg
Connectivity
Wi-Fi Standard Wi-Fi Certified 802.11b/g/n
Ethernet inputs 1 (Rear)
Bluetooth profile support No
Smartphone connectivity Screen mirroring(Miracast™)
RF (Terrestrial/Cable) Connection Input(s) 1 (Side)
IF (Satellite) Connection Input(s) No
Component Video (Y/Pb/Pr) Input(s) No
Composite Video Input(s) 1 (Bottom)
RS-232C Input(s) No
HDMI inputs total 2 (2Side)
HDCP HDCP1.4
HDMI-CEC Yes
MHL No
HDMI Audio Return Channel (ARC) Yes
Digital Audio Output(s) 1 (Side Hybrid with HP Out, Audio Out and Subwoofer Out with Digital Audio Out)
Audio/Headphone Output(s) 1 (Side Hybrid with Headphone Out, Audio Out and Subwoofer Out)
USB ports 2 (Side/Stacking)
USB HDD Recording No
USB drive format support FAT16/FAT32/NTFS
USB playback codecs MPEG1/MPEG2PS/MPEG2TS/AVCHD/MP4Part10/MP4Part2/AVI(XVID)/AVI(MotionJpeg)/WMV9/MKV/WEBM/WAV/MP3/WMA/JPEG
Picture (Panel)
Display LCD
Display resolution (H x V, pixels) 1920x1080
3D capability No
Backlight Edge LED
Backlight dimming Frame Dimming
Picture (processing)
HDR (High Dynamic Range) compatibility Yes
Picture processor No
Clarity enhancement X-Reality™ PRO
Colour enhancement TRILUMINOS™ Display
Contrast enhancement Dynamic Contrast Enhancer
Motion enhancer (Native Hz) Motionflow™ XR 200 (Native 50Hz)
Video signal support 1080p(30,50,60Hz), 1080/24p, 1080i(50,60Hz), 720p(30,50,60Hz), 720/24p, 576p, 576i, 480p, 480i
Picture modes Vivid,Standard,Custom,Cinema,Sports,Photo-Vivid,Photo-Standard,Photo-Custom,Game,Graphics,HDR Game,HDR Cinema
Sound (Speakers and Amplifier)
Audio Power Output 5W + 5W
Speaker Open Baffle Speaker
Sound (Processing)
Dolby audio format support Dolby™ Digital,Dolby™ Digital Plus,Dolby™ Pulse
DTS audio format support DTS Digital Surround
FM Radio Yes
Sound processing ClearAudio+
Simulated surround sound S-Force Front Surround
Sound modes Standard,Music,Cinema,Sports
Software
Operating System Linux
On-board Storage (GB) -
Display Language AFRIKAANS/ARABIC/ENGLISH/PERSIAN/FRENCH/INDONESIAN/PORTUGUESE/RUSSIAN/SWAHILI/THAI/TURKISH/VIETNAMESE/SIMPLIFIED CHINESE/ZULU
Text Input Language ENGLISH/FRENCH/PORTUGUESE/RUSSIAN/TURKISH/VIETNAMESE/SIMPLIFIED CHINESE
Content Bar No
Voice Search No
Electronic Program Guide (EPG) Yes
Internet Browser Opera(Depends on Country)
Application Store Yes(Opera Store)
On/Off Timer Yes
Sleep Timer Yes
Teletext Yes
Twin Picture No
Closed Captions (Analog/Digital) (Analog)-
Power and Energy saving
Screen Size (cm, measured diagonally) 108.0 cm
Screen Size (inch, measured diagonally) 43" (42.5")
Power Consumption (in operation) 75W
Annual Power Consumption* 100kWh/Year(Singapore)
Power Consumption (in standby) 0.50W
Power Consumption (Networked Standby Mode) – Terminals -
Peak luminance ratio for EU -
Presence of lead No
Mercury content(mg) -
Power Consumption (On Mode) for Energy Star -
Power Consumption (Standby Mode) for Energy Star -
Energy Star® compliant -
Power Requirements (voltage/frequency) AC 100-240V, 50/60Hz
Power Saving Mode / Back Light Off Mode Yes
Dynamic Backlight Control Yes
Light Sensor -
Design
Frame colour Black
Stand design Silver U Slate
Built-in Tuner
Number of Tuners (Terrestrial/Cable) 1(Digital/Analog)
Number of Tuners (Sat) -
TV System (Analog) B/G,D/K,I,M
Tuner Channel Coverage (Analog) 45.25MHz-863.25MHz(Depend on country/area selection)
TV System (Digital Terrestrial) DVB-T/T2
Tuner Channel Coverage (Digital Terrestrial) VHF/UHF(Depend on country/area selection)
TV System (Digital Cable) -
TV System (Digital Sat) -
CI+ -
************************************************************************
