Panasonic CS C18PKF 1.5 Ton Split Type AC QUICK OVERVIEW
Model (50Hz) CS-C18PKF (CU-C18PKF) Cooling/ Capacity Btu/h 18,000 - 18,000 kW 5.28 - 5.28 EER/ COP Btu/hW 9.47 - 9.23 Electrical Data Voltage V 220 - 240 Running Current A 8.8 - 8.9 Power Input W 1,900 - 1,950 Moisture Removal L/h 2.9 Pt/h 6.1 Air Circulation (Indoor/Hi) m⊃3;/min. 16.9 ft⊃3;/min. 597 Dimensions Height mm 290 (542) inch 11-7/16 (21-11/32) Width mm 1,070 (780) inch 42-5/32 (30-23/32) Depth mm 240 (289) inch 9-15/32 (11-13/32) Net Weight kg 12 (37) lb 26 (82) Refrigerant Pipe Diameter Liquid Side mm ø 6.35 inch 1/4 Gas Side mm ø 12.70 inch 1/2 Pipe Extension Chargeless Pipe Length m 7.5 Maximum Pipe Length m 25 Maximum Elevation Length m 20 Additional Refrigerant Gas* g/m 20 Power Supply Indoor
@@--------------------------------------------------------------------@@ |
