Specifications
Model year
2018
Dimensions and Weight
SCREEN SIZE (INCH, MEASURED DIAGONALLY)
85"(84.6")
SCREEN SIZE (CM, MEASURED DIAGONALLY)
214.8cm
DIMENSION OF TV WITHOUT STAND (W X H X D)
Approx. 1910x1096x73 mm
DIMENSION OF TV WITH STAND (W X H X D)
Approx. 1910x1176x396 mm
DIMENSION OF TV WITH FLOOR STAND (W X H X D)
-
DIMENSION OF PACKAGE CARTON (W X H X D)
Approx. 2088 x 1236 x 373 mm
STAND WIDTH
Approx. 1733 mm
VESA® HOLE PITCH(W X H)
400x400 mm
WEIGHT OF TV WITHOUT STAND
Approx. 45.2 Kg
WEIGHT OF TV WITH STAND
Approx. 48.2 Kg
WEIGHT OF TV WITH FLOOR STAND
-
WEIGHT OF PACKAGE CARTON (GROSS)
Approx. 67 kg
Connectivity
WI-FI STANDARD
Wi-Fi Certified 802.11a/b/g/n/ac
ETHERNET INPUTS
1 (Bottom)
BLUETOOTH PROFILE SUPPORT
Version 4.1;HID (mouse/keyboard connectivity)/HOGP (Low Energy device connectivity)/SPP(Serial Port Profile)/A2DP (stereo audio) 1/AVRCP (AV remote control)
SMARTPHONE CONNECTIVITY
Screen mirroring(Miracast™), Chromecast built-in, Video & TV SideView (iOS/Android)
RF (TERRESTRIAL/CABLE) CONNECTION INPUT(S)
1(Bottom)
IF (SATELLITE) CONNECTION INPUT(S)
No
COMPONENT VIDEO (Y/PB/PR) INPUT(S)
No
COMPOSITE VIDEO INPUT(S)
1 (Side)
RS-232C INPUT(S)
No
HDMI INPUTS TOTAL
4 (1Side,3Bottom)
HDCP
HDCP2.2(for HDMI™1/2/3/4)
HDMI-CEC
Yes
MHL
No
HDMI AUDIO RETURN CHANNEL (ARC)
Yes
DIGITAL AUDIO OUTPUT(S)
1 (Bottom)
AUDIO/HEADPHONE OUTPUT(S)
1 (Side/Hybrid with Headphone and Subwoofer Out)
USB PORTS
2 (Side) / 1 (Bottom)
USB HDD RECORDING
No
USB DRIVE FORMAT SUPPORT
FAT16/FAT32/exFAT/NTFS
USB PLAYBACK CODECS
MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/WAV/MP4AAC/FLAC/JPEG
Picture (Panel)
DISPLAY TYPE
LCD
DISPLAY RESOLUTION (H X V, PIXELS)
3840x2160
VIEWING ANGLE
-
3D CAPABILITY
No
BACKLIGHT TYPE
Direct LED
BACKLIGHT DIMMING TYPE
Local Dimming
Picture (processing)
HDR (HIGH DYNAMIC RANGE) COMPATIBILITY
Yes(HDR10, HLG)
PICTURE PROCESSOR
4K HDR Processor X1™ Extreme
CLARITY ENHANCEMENT
4K X-Reality™ PRO, Dual database processing
COLOUR ENHANCEMENT
TRILUMINOS™ Display, Super bit mapping™ 4K HDR, Live Colour™ Technology, Precision Colour Mapping
CONTRAST ENHANCEMENT
X-tended Dynamic Range™ PRO, Object-based HDR remaster, Dynamic Contrast Enhancer
MOTION ENHANCER (NATIVE HZ)
X-Motion Clarity
VIDEO SIGNAL SUPPORT
HDMI™ signal :4096x2160p(24,50,60Hz), 3840x2160p(24,25,30,50,60Hz), 1080p(30,50,60Hz), 1080/24p, 1080i(50,60Hz), 720p(30,50,60Hz), 720/24p, 576p, 576i, 480p, 480i
PICTURE MODES
Vivid,Standard,Custom,Cinema Pro,Cinema Home,Sports,Animation,Photo-Vivid,Photo-Standard,Photo-Custom,Game,Graphics
HEVC SUPPORT
-
Sound (Speakers and Amplifier)
AUDIO POWER OUTPUT
10W+10W
SPEAKER TYPE
Bass Reflex Speaker
Sound (Processing)
DOLBY AUDIO FORMAT SUPPORT
Dolby™ Digital, Dolby™ Digital Plus, Dolby™ Pulse
DTS AUDIO FORMAT SUPPORT
DTS Digital Surround
FM RADIO
No
SOUND PROCESSING
ClearAudio+
SIMULATED SURROUND SOUND
S-Force Front Surround
SOUND MODES
Standard,Dialog,Cinema,Music,Sports
Software
OPERATING SYSTEM
Android™
ON-BOARD STORAGE (GB)
16GB
CONTENT BAR
Yes
VOICE SEARCH
Yes
ELECTRONIC PROGRAM GUIDE (EPG)
Yes
INTERNET BROWSER
Vewd
APPLICATION STORE
Yes(Google Play Store)
ON/OFF TIMER
Yes
SLEEP TIMER
Yes
TELETEXT
Yes
TWIN PICTURE
No
CLOSED CAPTIONS (ANALOG/DIGITAL)
(Analogue)-, (Digital)Subtitle
Power and Energy saving
ENERGY LEVEL RATING
-
SCREEN SIZE (CM, MEASURED DIAGONALLY)
214.8cm
SCREEN SIZE (INCH, MEASURED DIAGONALLY)
85"(84.6")
POWER CONSUMPTION (IN OPERATION)
380W
ANNUAL POWER CONSUMPTION*
429 kWh/Year 2
POWER CONSUMPTION (IN STANDBY)
0.5W
POWER CONSUMPTION (NETWORKED STANDBY MODE) – TERMINALS
-
PEAK LUMINANCE RATIO FOR EU
-
PRESENCE OF LEAD
No
MERCURY CONTENT(MG)
-
POWER CONSUMPTION (ON MODE) FOR ENERGY STAR
-
POWER CONSUMPTION (STANDBY MODE) FOR ENERGY STAR
-
ENERGY STAR® COMPLIANT
-
POWER REQUIREMENTS (VOLTAGE/FREQUENCY)
50/60Hz, AC 110-240V
POWER SAVING MODE / BACK LIGHT OFF MODE
Yes
DYNAMIC BACKLIGHT CONTROL
Yes
LIGHT SENSOR
Yes
Design
FRAME COLOUR
Black
STAND DESIGN
Silver L-Shape
Built-in Tuner
NUMBER OF TUNERS (TERRESTRIAL/CABLE)
1(Digital/Analog)
NUMBER OF TUNERS (SAT)
-
TV SYSTEM (ANALOG)
B/G,D/K,I,M
TUNER CHANNEL COVERAGE (ANALOG)
45.25MHz-863.25MHz(Depend on country/area selection)
TV SYSTEM (DIGITAL TERRESTRIAL)
DVB-T/T2
TUNER CHANNEL COVERAGE (DIGITAL TERRESTRIAL)
VHF/UHF(Depend on country/area selection)
TV SYSTEM (DIGITAL CABLE)
-
TV SYSTEM (DIGITAL SAT)
-
CI+
-
What's In The Box
Table Top Stand
Voice Remote Control
Batteries
AC Power Cord
Operating Instructions
