HANVON M2000 Face Access Control & Time Attendance

HANVON Face Access Control & Time Attendance

Product description:
1. Biometric performance reliable, durable and highly accurate ZK fingerprint sensor with ver.10 Algorithm provides less than 1.5second user recognition
2. Easy operation and management:
Works without computer. Complete set up and programming can be done via keypads and embedded firmware. Graphical user interface on a 3.5-inch TFT display for rich user experience. AudioVisual indication for acceptance and rejection of valid/invalid fingerprints
3. Full access control built-in relay outputs for electric lock and alarm. Inputs for door status sensor and exit switch. Supports multiple timezones and personnel groups for programming valid entry zones. The alarm will be triggered when the tamper switch is activated.
4. Communication Weigand output for connecting to access control panel and Ethernet port for fast and reliable communication with the computer.

Face capacity: 2000 templates
Fingerprint capacity: 3000 templates
ID card capacity: 10,000
Transaction capacity: 200,000
Sensor: optical sensor
Algorithm version: finger v10.0
Communication: RS232/485, TCP/IP, USB-host
Access control interface for 3rd party electric lock, door sensor, exit button, alarm, door bell
Wiegand signal: output and input
Display: TFT LCD screen
Standard function: ID card, Webserver, DLST
Optional function: Mifare card
Power supply: 12V DC
Operating temperature: 0 - 45°C
Operating humidity: 20%-80%
