Walton Fridge

Cooling Features :
Type Direct Cool
Capacity :
Gross Volume (Outer Dimension, Manufacturer declared) 213 Ltr.
Net Volume 176 Ltr.
Net Weight 45.5 ± 2 Kg
Gross Weight 53 ± 2 Kg
Performance :
Climatic Type (SN, N, ST, T) N~ST
Rated Voltage/ Hz 220 ~ 240/ 50
Compressor Input Power (Watt) V 1001- 119
V 1002- 119
V 1101- 102
V 1102- 102
V 1201- 109
V 1301- 108.6
Compressor Type RSCR
Cooling Effect Freezer Cabinet Less than -18℃
Refrigerator Cabinet 0℃ to +5℃
General Features :
Temperature Control (Electronic/ Mechanical) Mechanical
Defrosting (Automatic/ Manual) Manual
Reversible Door No
Handle (Recessed/ Grip) Recessed/ Grip
Lock Yes
Refrigerant V 1001- R134a
V 1002- R134a
V 1101- R600a
V 1102- R600a
V 1201- R134a
V 1301- R600a
Thermostat RoHS Certified
Condenser Copper
Capillary Copper
Polyurethane foam blowing agent CycloPentane
[Eco-friendly (100% CFC &
HCFC Free) Green Technology]
Recommended voltage stabilizer capacity V10.01/ V10.02/ V12.01: 1000VA
V11.01/ V11.02/ V13.01: No Need to use voltage stabilizer.
If out of voltage range(145V-260V),
then suggested voltage stabilizer capacity is 1000VA.
Refrigerator Compartment :
Shelf (Material/ No.) Wire/2
Door Basket PVC/2
Interior Lamp Yes
Vegetable Crisper Yes/1
Vegetable Crisper Cover Yes
Egg Tray or Pocket Yes/1
Can Storage Dispenser No
Deodorizer No
Freezer Compartment :
Shelf (Material/ No) Wire/2
Drawer No
Door Basket No
Interior Lamp No
Dimensions (Net) :
Width/mm 542
Depth/mm 618
Height/mm 1500
Packing :
Width/mm 580
Depth/mm 635
Height/mm 1520
Loading Capacity- 40HQ/ 40Ft/ 20Ft 103/ 103 /50
