TURKEY Made Good Price Residential Passenger Elevator

We support our customers entire Bangladesh throughout their project life cycle, from the design through to the end-of-life phase. Every step of the way, we strive to fully understand their needs and consistently deliver the safest, highest quality passenger transportation solutions.

Basic Info.

Brand : SEYKA

Person : 08 (630KG)

Stops : 06

Control Mode : Group Control

Elevator Door : Center Opening Door

Door Knife : Single

Control System : Vvvf Drive

Material : 304 Stainless Steel

Speed : 1.0m/S-4.0m/S

Machine Room : Accept Customization

Safety Device : Safety Gear

Energy Saving : More Than 50%

Decoration : OEM & ODM

Application : Hotel/Office Building/Hospital/ Home

Trademark : SEYKA

Transport Package : Box

Specification : many types for your choice

Origin : TURKEY

 Higher transport capacity and efficiency

 More efficient use of building floor space

 Reduced energy consumption

 Maximum availability of existing passenger transportation solutions

 Product Introduction:

Owning both advanced technology and sophisticated functional configuration,

we have integrated high-end allocation, efficiency, smartness and energy saving, etc.

outstanding features into one and comprehensively applied various fields of technologies,

such as information, environment, energy and so on,

making contribution to creating rich and colorful urban life.

**Features

 Mutual communication brings double safety : Dual motherboard + dual encoder

Both the sides of motherboard and speed governor are installed with encoders at the same time that are separately connected with integrated machine and select panel.

Two main control systems communicate and monitor each other.

If one of them makes an error, the terminal speed governor would be cut off and make the elevator stop safely.

 To move with the flow to reduce the friction : A new type of roller guide shoe

The sliding friction has been replaced by rolling friction to reduce more than 47% of frictional loss for more efficient energy-conservation.

Small contact area and flexible support contribute to vibration lighter and feeling more comfortable.

There is no need to use guide rail lubricating oil, which is more environment-friendly by reducing maintenance.

 Perfect curve for proper opening and closing : Permanent magnet synchronous door operator

The optimized S-Curve creates smooth and steady door switch and smaller load shock of electrical machine.

An outstanding self-adaptive control can response to various interference factors by self-check, self-adaptation and self-regulation.

The huge polyurethane roller has a strong wear-resistance and has realized a silence running.

 Double-protection for nipping in the bud : Light curtain + safety edge

A new generation of double-protection of safety edge and infrared ray has been applied for more safety and reliability. The quantity of light curtain beams is 154, so the detection is more comprehensive and safer. IP54 of protection grade completely prevents the equipment from water and dust.

 The functions of brake self-detection and self-monitor

In normal running condition, the elevator detects its brake on certain time every day. Once it is insufficient, the elevator will immediately stop its operation and display fault to ensure the safety of passengers at first time.

 Sliding detection of hoist rope

As the increasing hours of use of the elevator, the friction force between hoist rope and hoist running wheel groove will ceaselessly reduce and lead to slipping of hoist rope, ranging from low precision of elevator leveling to free slipping phenomenon of car that causes personal injury.

 Installation Process Characters

** Most of the manufacturing and assembly of the equipment is completed in the manufacturing plant. Therefore, the on-site installation schedule is short, usually installations are currently about 30 days.

** The frame-integrated elevator is not only suitable for the installation of various types of multi-layer external elevators but also can be flexibly used for the installation of elevators in indoor buildings.

** The integrated elevator of the frame does not need to have an elevator shaft, a machine room, or a space for occupying the original building treasure in the building.

** The frame-integrated elevator is suitable for use in elevators of various types of multi-story buildings, and it can be well connected with various brick structures and cement buildings.
