MJPEG (APM-J011) Powerful high-speed video protocol processor MJPEG video compression Support two-way audio function High-sensitivity CMOS sensor Resolution: 640 x 480(VGA), 320 x 240(QVGA) Video Frame Rate: 30fps (QVGA), 15fps (VGA) Minimum Illumination: 0.5Lux @ F2.0 IR night vision (Range: 10~15m) Specification: Model: APM-J011 Image Sensor Image Sensor 1/4" Color CMOS Sensor Display Resolution 640 x 480 Pixels(300k Pixels) Lens f: 6 mm, F:2.0 (IR Lens) (3.6mm lens optional) Mini. Illumination 0.5Lux Lens Lens Type Glass Lens Viewing Angle 60 Degree (3.6mm lens is 90Degree) Audio Input Built-in Microphone Output Built-in Speaker Audio Compression ADPCM Video Image Compression MJPEG Image Frame Rate 15fps(VGA),30fps(QVGA) Resolution 640 x 480(VGA), 320 x 240(QVGA) Flip Mirror Images Vertical / Horizontal Light Frequency 50Hz, 60Hz or Outdoor Video Parameters Brightness, Contrast Communication Ethernet Interface Build in 10/100Mbps,Auto MDI/MDIX , RJ-45 Supported Protocol HTTP,FTP,TCP/IP, UDP, SMTP, DHCP, PPPoE, DDNS, UPnP, GPRS Physical Pan/Tilt Angle Horizontal:270° & Vertical: 120° Infrared Light 10 IR LEDs, Night visibility up to 10 meters Alarm Input 1 Channel on/off Input Alarm Output 1 Channel relay Output Dimension 100(L) x100(W) x120mm(H) Gross Weight 750g Color Box 210 x 130 x 190 mm Net Weight 550g ( accessories included) Power Power Supply DC 5V/2.0A ( EU,US<, /st1:place>,AU adapter or other types optional) Power Consumption 5 Watts (Max.) POE Optional Environment Operate Temper. 0° ~ 55°C (14°F ~ 131°F) Operating Humidity 20% ~ 85% non-condensing Storage Temper. -10°C ~ 60° (14°F ~ 140°F) Storage Humidity 0% ~ 90% non-condensing PC System Requirements CPU 2.0GHZ or above (suggested 3.0GHz) Memory Size 256MB or above (suggested 1.0GHz) Display Card 64M or above Supported OS Microsoft Windows 2000/XP/Vista/7 Browser IE6.0/7.0/8.0/Firefox/Safari/Google chrome or other standard browsers Certification CE, FCC, RoHS Warranty Limited 1-year warranty |
