EPSON-EMP811 LCD projector

Size 0.9inches without MLA (x3)
Driving method Poly-Silicon TFT active matrix
Pixel number 786,432 (1024 x 768) x 3
Native resolution XGA
Aspect ratio 4:3
Pixel arrangement Stripe
PROJECTION
Type Manual: zoom / focus
f-number 1.74 to 2.06
f-number 28.3 to 37.98mm
Zoom ratio 1:1.35
Lens cover attached
LAMP
Type 200 W UHE
OPTICAL SYSTEM
Dichroic Mirror Separation & Prism combine method
SCREEN SIZE (PROJECTED DISTANCE) 30 to 300inch (0.87 to 12.48m)
KEYSTONE CORRECTION RATIO 10:0
BRIGHTNESS 2000 Lumens
CONTRAST 400:1
BRIGHTNESS UNIFORMITY 85%
COLOUR REPRODUCTIVITY Full colour (16.7 million colours)
SOUND OUTPUT 5W
EFFECTIVE SCANNING FREQUENCY RANGE
PIXEL CLOCK 14MHz to 230MHz
HORIZONTAL (15 - 107) KHz
VERTICAL (43 - 120) Hz
ADJUSTMENT FUNCTION
PROJECTOR / REMOTE CONTROL Keystone (Vertical and Horizontal) / Brightness / Contrast / Tint / Sound / Input signal etc.
KEYSTONE CORRECTION Vertical -30 to +30 degrees
Horizontal -10 to +10 degrees
TILT ANGLE 0 to 12 degrees
ANALOGUE RGB I/O
DISPLAY PERFORMANCE
Native 1024 x 768 dots
Resize 1600 x 1200 / 1280 x 1024 / 800 x 600 / 640 x 480 dots
INPUT SIGNAL
Signal type Separate signal
Video signal Analogue (0.7Vp-p,75 / Mac 0.714Vp-p,75 )
Sync. signal Separate (positive & negative, bi-polarity 1-5Vp-p) /
Composite (positive & negative, bi-polarity 1-5Vp-p) / Sync. on green (negative.0.3Vp-p)
Audio signal 500m Vrms / 47 K
INPUT TERMINAL
Video DVI Type I x 1(DDC 2B compatible, Analogue / Digital auto detect) Mini D-sub 15 pin x 1
Audio Stereo mini jack RCA x 2
OUTPUT SIGNAL
Video signal Analogue (0.7Vp-p,75 / Mac 0.714Vp-p,75 )
Sync. signal Separate (positive & negative, bi-polarity1-5Vp-p) /
Composite (positive & negative, bi-polarity1-5Vp-p) / Sync. on green (negative 0.3Vp-p)
OUTPUT TERMINAL
Video Mini D-sub 15pin x 1
DIGITAL RGB INPUT
DISPLAY PERFORMANCE
Native 1024 x 768 dots
Resize 1280 x 1024 / 800 x 600 / 640 x 480 dots
INPUT SIGNAL
Video signal Digital
Audio signal 500m Vrms / 47 K
INPUT TERMINAL
Video DVI Type I x 1 (DDC 2B compatible, Analogue/Digital auto detect)
Audio Stereo mini jack
VIDEO I/O
DISPLAY PERFORMANCE NTSC: 550 lines PAL: 550 lines (Depend on observation of the multi burst pattern)
INPUT SIGNAL Video standard NTSC / NTSC4.43 / PAL / M-PAL / N-PAL / PAL60 / SECAM
Video signal Composite Video (1.0Vp-p/ Sync.negative, 75 ohm) /
S- Video (Luminous0.714Vp-p, Chrominous 0.286Vp-p, 75 ohm) /
Component Video (Analogue Y level 0.7V 75 ohm/ Cr Cb level +/-0.35V 75 ohm/ sync.negative 0.3V or 3-state+/-0.3V on Y) /
Video-RGB (0.7Vp-p, 75 ohm/ Mac 0.714Vp-p,75 ohm)
Audio signal 500m Vrms / 47 K
INPUT TERMINAL
Video Composite Video: RCA x 1 / S-Video: Mini DIN /
Component Video: Mini D-sub 15pin / Video-RGB: Mini D-sub 15pin
Audio RCA x2 (for Composite Video/S-Video / Component Video) Stereo mini jack (for Video-RGB)
CONTROL I/O MOUSE I/O / USB I/O
I/O terminal Mini DIN 9pin x1 (for PS/2 mouse) / USB connector series A x1 (for HUB) USB connector series B x1 (for mouse, K/B, audio, control)
SERIAL I/O
I/O terminal Mini D-sub 9pin x1
I/O serial RS-232C
INPUT TERMINAL
Remote Control Stereo mini jack x1
OPERATING TEMPERATURE
5°C to 35°C (41°F to 95°F) (20% to 80% Humidity)
POWER SUPPLY VOLTAGE
100 - 120V / 200 - 240V ±10%, 50/60Hz AC
DIMENSION
EXCLUDE PROJECTION LENS & FEET 348(W) x 104(H) x 274(D)mm
MAXIMUM DIMENSION 349(W) x 114(H) x 276(D)mm
WEIGHT Approx. 9.3lbs / 4.2Kg
FAN NOISE 38dB
