DELL™ LATITUDE

System Information System chipset AMD™ M690T Chipset with ATI™ Radeon® X1270 Graphics Data bus width 64 bits DRAM bus width dual-channel (2) 64-bit buses Processor address bus width 40 bits Flash EPROM 2 MB Graphics bus internal PCI bus 32 bits PC Card CardBus controller O2Micro OZ711EZ1 (PC Cards and 34-mm ExpressCards) (support for USB ExpressCard™ through adapter in PC Card slot) PC Card connector one (supports one Type I or Type II card and one 34-mm ExpressCard with adapter) NOTE: You must use an adapter with the 34-mm ExpressCard before you insert the card into the PC Card connector. Cards supported 3.3-V and 5-V PC Cards 1.5-V ExpressCards (with adapter) PC Card connector size 68 pins Data width (maximum) PCMCIA 16 bits CardBus 32 bits Memory Memory module connector two user-accessible SODIMM sockets Memory module capacities 512 MB, 1 GB, and 2 GB Memory type 533/667-MHz DDR2 SDRAM (single channel and dual channel compatible) Minimum memory 512 MB Maximum memory 4 GB Ports and Connectors Serial 9-pin connector; 16550C-compatible, 16-byte buffer connector Audio microphone miniconnector, stereo headphones/speakers miniconnector S-video TV-out 7-pin mini-DIN connector (optional adapter cable(s) with S-video and composite video connectors) VGA VGA (analog) connector (on computer, and on D/Dock and D/Port port replicators): supports monitors with resolutions up to 1920 x 1200 (WUXGA) at 60-Hz refresh rates for flat-panel displays and 1600 x 1200 (UXGA) at 85-Hz refresh rates for CRT monitors DVI DVI (digital) connector (through D/Port and D/Dock port replicators): supports flat panel displays with resolutions up to 1920 x 1200 (WUXGA) at 60-Hz refresh rates USB four 4-pin USB 2.0-compliant connectors Modem RJ-11 support IEEE 1394a 4-pin serial connector Mini-Card one Type IIIA Mini-Card connector Network adapter RJ-45 port Docking D/Port advanced port replicator D/Dock compatible (PCI connector not supported) Communications Modem: Type v.92 56K MDC Controller softmodem Interface Azalia Network adapter 10/100/1000 Ethernet LAN on system board Wireless LAN • Internal PCI-e Mini-Card WLAN support • 802.11a/b/g, with scalability to 802.11n/3x3 MIMO • Dual Band and Single Band card support • Antennae support for 802.11n/MIMO • Three Dual-band (2.4/5-GHz) antennas • Support for Wake on Wireless (WoWLAN) Wireless PAN (Bluetooth wireless technology) • Bluetooth® wireless technology version 2.1 + Enhanced Data Rate • Backward compatible with Bluetooth wireless technology version 1.2 and 2.0 • Support for WLAN /Bluetooth wireless technology collaborative co-existence scheme Wireless WAN (cellular) WWAN support via ExpressCard with adapter in PC Card/ExpressCard slot • CDMA EVDO rev 3.6 • HSDPA/HSUPA (3G) rev A Video Video type ATI Radeon™ Xpress X1270 integrated graphics Graphics API compliance • OpenGL 1.4 or later • DirectX 9 or later Local frame buffer 32 MB Maximum video memory • Up to 64 MB (shared) for 512 MB of system memory • Up to 256 MB (shared) for 1 GB or more of system memory LCD interface LVDS TV support NTSC or PAL in S-video and composite modes (through Dell™ D/Port advanced port replicator only) Audio Audio type High Definition Audio (HDA) Audio controller SigmaTel STAC9205 Stereo conversion 24-bit (digital-to-analog) 24-bit (analog-to-digital) Interfaces: Internal HDA (Azalia/AC'97) External microphone mini-connector, stereo headphones/speakers mini-connector Microphone Integrated omni-direction analog microphone Speaker two 4-ohm speakers Internal speaker amplifier 2-W per channel into 4 ohms Volume controls keyboard shortcuts or program menus Display Type (active-matrix TFT) 14.1-inch WXGA 15.4-inch WXGA 15.4-inch WXGA + TrueLife™ Dimensions (14.1-inch display): Height 214.3 mm (8.4 inches) Width 285.7 mm (11.3 inches) Diagonal 357.1 mm (14.1 inches) Dimensions (15.4-inch display): Height 222.5 mm max (8.7 inches) Width 344.5 mm (13.56 inches) Diagonal 391.16 mm (15.4 inches) Operating angle 0° (closed) to 180° Viewing angles: WXGA horizontal +/– 40/40° WXGA vertical +/– 10/30° Pixel pitch: WXGA 0.2588 mm(15.4-inch display) Power consumption (panel with backlight) (typical): WXGA 5.0 W (maximum) Controls Brightness can be controlled through keyboard shortcuts and through QuickSet. Keyboard Number of keys 87 (U.S. and Canada); 87 (China); 89 (Brazil); 88 (Europe); 91 (Japan) Key travel 2.7 mm ± 0.3 mm (0.11 inch ± 0.016 inch) Key spacing 19.05 mm ± 0.3 mm (0.75 inch ± 0.012 inch) Layout QWERTY/AZERTY/Kanji Touch Pad X/Y position resolution (graphics table mode) 240 cpi Size: Width 64.88-mm (2.55-inch) sensor-active area Height 48.88-mm (1.92-inch) rectangle Battery Primary Type 4-cell "smart" lithium ion (32 WHr) 6-cell "smart" lithium ion (56 WHr) 9-cell "smart" lithium ion (85 WHr) Secondary Type Lithium Polymer (48 WHr) in D-Module NOTE: Some auto/air adapters may not have sufficient wattage to charge a 9-cell battery, but they will still power the computer. Weight 0.26 kg (0.57 lb) (4 cell) 0.35 kg (0.78 lb) (6 cell) 0.48 kg (1.1 lb) (9 cell) Voltage 14.8 VDC (4 cell) 11.1 VDC (6 cell) Charge time (approximate): Computer on 2.5 hours Computer off approximately 1 hour for 80 percent charge Operating time varies depending on operating conditions and can be significantly reduced under certain power-intensive conditions. See Battery Performance for more information. Life span (approximate) 500 discharge/charge cycles Temperature range: Operating 0° to 35°C (32° to 95°F) Storage –40° to 65°C (–40° to 149°F) AC Adapter Types 65 W and 90 W Input voltage 90-264 VAC (65 W and 90 W) Input current (maximum) 1.7 A (65 W and 90 W) Input frequency 47–63 Hz (65 W and 90 W) Output current: 65 W 4.34 A (maximum at 4-second pulse) 3.34 A (continuous) 90 W 5.62 A (maximum at 4-second pulse) 4.62 A (continuous) Rated output voltage 19.5 VDC (65 W and 90 W) Dimensions and weight: Height 27.8.–28.6 mm (1.10–1.12 inches) (65 W) 33.8–34.6 mm (1.34–1.36 inches) (90 W) Width 57.9 mm (2.28 inches) (65 W) 60.9 mm (2.39 inches) (90 W) Length 137.2 mm (5.40 inches) (65 W) 153.4 mm (6.04 inches) (90 W) Weight (without cables) 0.36 kg (0.79 lb) (65 W) 0.46 kg (1.01 lb) (90 W) Temperature range: Operating 0° to 35°C (32° to 95°F) (65 W and 90 W) Storage –40° to 65°C (–40° to 149°F) (65 W and 90 W) Physical Height 35 mm (1.37 inches) Width 361 mm (14.2 inches) Depth 262.2 mm (10.3 inches) Weight approximately 6.0 lb (2.7 kg), with a 14.1-inch XGA display, Dell TravelLite™ module, and 6-cell battery; weight varies, depending on configuration and manufacturing variability Environmental Temperature range: Operating 0° to 35°C (32° to 95°F) Storage –40° to 65°C (–40° to 149°F) Relative humidity (maximum): Operating 10% to 90% (noncondensing) Storage 5% to 95% (noncondensing) Maximum vibration (using a random-vibration spectrum that simulates user environment): Operating 0.66 GRMS Storage 1.30 GRMS Maximum shock (measured with hard drive in operating status and a 2-ms half-sine pulse for operating; also measured with hard drive in head-parked position and a 2-ms half-sine pulse for storage): Operating 142 G, 70 inches/sec Storage 163 G, 80 inches/sec Altitude (maximum): Operating –15.2 to 3048 m (–50 to 10,000 ft) Storage –15.2 to 10,668 m (–50 to 35,000 ft) Airborne contaminant level G2 or lower as defined by ISA-S71.04-1985
