Esonic G41 Intel Chipset Motherboard

CHIPSET : INTEL G41 , SUPPORT 1XDDR2 /1XDDR3 FSB1333MHZ

কন্ডিশন ফ্রেশ। কোন প্রব্লেম নাই। টেস্ট করে দিব। কল না ধরলে একটা মেসেজ দিয়ে রাখবেন যেন আমি কলব্যাক করতে পারি। ক্লাস এবং নামাজের সময়ে কল ধরতে পারবো না।

Supports Intel® Core 2 Quad/Core 2 Duo based processors in LGA775 package.
Supports Intel® Yorkfield, Wolfdale in the LGA775 package.
Supports Intel® next generation 45nm multi-core processors
Supports FSB 1333/1066/800 MHz.
Supports VRD 11.1 standard.
Supports FMB 05a@95W

Main Memory
Supports 1XDDR2 ,1XDDR3

Slots
One PCI Express x16 slot (PCI Express Bus SPEC V1.0 compliant).
Two 32-bit v2.3 master PCI bus slots.
- Support 3.3v/5v PCI bus interface.

On-Board IDE/SATA

One Ultra DMA 66/100 IDE controller integrated in Intel® ICH7.
- Supports PIO, Bus Master operation modes.
- Can connect up to two Ultra ATA drives.

SATAII controller integrated in ICH7 chipset
- Up to 3Gb/s transfer speed.
- Supports four SATAII ports by ICH7

Audio
Chipset integrated by Realtek® ALC
- Flexible 5.1-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
- Meet Microsoft Vista Premium spec


LAN
Supports PCI Express LAN 10/100/1000 Fast Ethernet by Realtek 8111DL


Internal I/O Connectors
- ATX 24-Pin power connector
- 4-pin ATX 12V power connector
- CPU x1/ System x2 FAN connectors
- CD-in connector
- Front panel audio connector
- Front panel connector
- 2 x USB 2.0 connectors
- 1 x Floppy disk drive connector
- 2 x Serial ATAII connectors
- 1 x ATA100 connector
- Clear CMOS Jumper



Back Panel I/O Ports
- 1 x PS/2 keyboard
- 1 x PS/2 mouse
- 1 x Parallel port
- 1 x Serial port (COM 1)


- 1 x Graphics Card port
- 1 x 3 in 1 audio jack
- 4 x USB 2.0 ports
- 1 x RJ45 LAN jack


Socket Type: LGA 755
Form Factor: ATX
Memory Type: DDR2
Graphics Card Type: Integrated
