MIKROTIK Ethernet Router CCR1036-8G-2S+EM

One year warranty
Our fastest router has now become even better - the new CCR1036-8G-2S+ now has two SFP+ ports for 10G interface support (SFP+ module available separately). It uses the same 36 core Tilera CPU as our other CCR1036 model, and delivers the same performance, but now, ten gigabit links are possible.

The device comes in a 1U rackmount case, has two SFP+ ports, eight Gigabit ethernet ports, a serial console cable and a USB port.

The CCR1036-8G-2S+ has two SODIMM slots, by default it is shipped with 4GB of RAM, but has no memory limit in RouterOS (will accept and utilize 16GB or more). Also available now, the EM model with 16GB of RAM!
Supports both SFP (1.25G) and SFP+ (10G) modules
Product specifications
Details
Product code CCR1036-8G-2S+EM
SFP DDMI Yes
CPU nominal frequency 1.2 GHz
CPU core count 36
Architecture TILE
Size of RAM 16 GB
10/100 Ethernet ports 0
10/100/1000 Ethernet ports 8
MiniPCI slots 0
MiniPCI-e slots 0
Number of USB ports 1
Memory Cards 1
Memory card type microSD
Power Jack 1
Supported input voltage 28 V - 18 V
PoE in No
PoE out No
Voltage Monitor Yes
CPU temperature monitor Yes
PCB temperature monitor Yes
Dimensions 355x145mm55mm
Operating System RouterOS
Operating temperature range -30C to +60C
License level 6
Antenna gain DBI No
Current Monitor Yes
CPU TLR4-03680CG-12CE-A3b
SFP ports 0
SFP+ ports 2
USB slot type microUSB type AB
Number of chains 0
Serial port RS232
