CISCO WS-C2960-24TT-L V03 VEthernet Switch
Lowest price in Bangladesh:
Highlights
- Brand: CISCO
- Type: Switch
Seller info
Sold by:
APC UPS
Member since:
29 Jul 2018
Location:
Dhaka Dhanmondi
Safety tips:
Don’t pay in advance
Meet in a safe & public place
Meet in a safe & public place
Description
DESCRIPTION for CISCO WS-C2960-24TT-L V03 VEthernet Switch price in Bangladesh
|
Model Brand : CISCO Series : Catalyst 2960 Model : WS-C2960-24TT-L Format & Standards Standards IEEE 802.1s IEEE 802.1w IEEE 802.1x IEEE 802.3ad IEEE 802.3ah (100BASE-X single/multimode fiber only) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.1D Spanning Tree Protocol IEEE 802.1p CoS Prioritization IEEE 802.1Q VLAN IEEE 802.3 10BASE-T specification IEEE 802.3u 100BASE-TX specification IEEE 802.3ab 1000BASE-T specification IEEE 802.3z 1000BASE-X specification Ports & Interface Primary Ports : 24 Ethernet 10/100 ports and 2 10/100/1000-TX uplinks Primary Port Speed : 10/100Mbps Ports + 1000Mbps Uplinks Data Transmission MAC Address Table : Up to 8000 VLAN Support : Yes Jumbo Frames : Yes Details Buffer Memory : 64 MB DRAM 32 MB flash memory Cabling 10BASE-T ports : RJ-45 connectors, two-pair Category 3, 4, or 5 unshielded twisted-pair (UTP) cabling 100BASE-TX ports : RJ-45 connectors, two-pair Category 5 UTP cabling 1000BASE-T ports : RJ-45 connectors, four-pair Category 5 UTP cabling 1000BASE-T SFP-based ports: RJ-45 connectors, four-pair Category 5 UTP cabling 1000BASE-SX, -LX/LH, -ZX, -BX and CWDM SFP-based por : LC fiber connectors (single/multimode fiber) 100BASE-LX, -BX, -FX : LC fiber connectors (single/multimode fiber) LEDs Per-port status: Link integrity, disabled, activity, speed, full-duplex System status: System, RPS, link status, link duplex, link speed Power Maximum Power Consumption : 30W AC Input Voltage and Current : 100-240VAC (autoranging), 1.3-0.8A, 50-60 Hz Power Rating : 0.05kVA DC Input Voltages (RPS Input): +12V at 5A Features 1 RU fixed-configuration, multilayer switch Entry-level enterprise-class intelligent services LAN Base Image installed Ease of Use and Deployment Superior Redundancy for Fault Backup Advanced QoS 16 Gbps switching fabric Forwarding rate based on 64-byte packets: 6.5 Mpps Dimensions : 17.5" x 9.3" x 1.7" Weight : 8.0 lbs. Temperature : 0ºC to 45ºC (32ºF to 113ºF) Humidity : 10 to 85% (noncondensing) |
