40 Ton Load Cell Zemic

Zemic Suiioble for Dusl & water proven (lP 65)2mv/v
load cell for truck scale 40 ton HM9B

Overview
Specifications
Place of Origin: China (Mainland)
Brand Name: Zemic
Model Number: HM9B
Usage: Consumption Sensor
Theory: Resistance Sensor
Output: Analog Sensor
iterm: Zemic 40 ton HM9B load cell for truck scale Packaging & Delivery
Packaging Details: OIML weighing scale parts load cell price package :cartons and pallet
Delivery Detail: 15 working days since the payment
Zemic 40 ton HM9B load cell for truck scale
Products specification
1.HM9B load cell are available in the capacities 10t to 50t.
2.Alloy steel construction, nickel plated , hermetically welded,oil-proof,waterproof and anti-corrosive gas and medium making ,it suitable for all kinds of environments.
3. Dual shear beam, Suitable for electronic truck scales,railway scales and other electronic weighing devices.
4.It is safety and anti-explosion product that can be used in atrocious weather and hazardous areas.
The heart of any weighing system is the load cell. A load cell is an electrical instrument which is used to convert a mechanical force into an electrical output signal. The terminology for load cells can be found in the OIML R60 regulation for load cells.
Load cells are highly accurate trans­ducers which pro­vides the user with informa­tion not generally obtainable by other technology due to commercial fac­tors. Load cells are designed to sense force or weight under a wide range of adverse condi­tions. They are not only the most essen­tial part of an elec­tronic weighing system, but also the most vulnerable. In order to get the most bene­fit from the load cell, the user must have a thor­ough understanding of the technology, con­struction and oper­ation of this unique device. In addition, it is imperative that the user selects the cor­rect load cell for the appli­cation and pro­vide the necessary care for the load cell during its lifetime.
Understanding these important issues and pro­perly maintaining the load cells will ensure trou­ble-free weighing for a long period of time.
OIML shear beam load cell Specifications
Capacity
10/20/25/30/40SE/40/50
Accuracy
C1
C2
C3
A5M
B10M
Approvals
OIML R60 C3
Maximum number of
verification intervals
n max
1000
2000
3000
5000
10000
Minimum load cell
verification interval
v min
Emax/3000
Emax/5000
Emax/7500
Emax/15000
Emax/10000
Combined error
(%FS)
≤±0.050
≤±0.030
≤±0.020
≤±0.026
≤±0.050
Creep
(%FS/30min)
≤±0.038
≤±0.024
≤±0.016
≤±0.017
≤±0.040
Temperature effect
on sensitivity
(%FS/10℃)
≤±0.028
≤±0.017
≤±0.011
≤±0.013
≤±0.040
Temperature effect
on zero
(%FS/10℃)
≤±0.047
≤±0.023
≤±0.015
≤±0.014
≤±0.020
Output sensitivity
(mv/v)
2.0±0.002
2.3±0.002
2.4±0.002
1.9±0.002
1.8±0.002
Input resistance
(Ω)
700 ±7
775 ±5 750 ±7
Output resistance
(Ω)
700 ±7
Insulation resistance
(MΩ)
≥ 5000(50VDC)
Zero balance
(%FS)
1.5

Temperature, compensated

(℃)

-10~+40

Temperature,allowed

(℃)

-35~+65

Excitation, Recommended

(V)

5~12(DC)

Excitation,Max

(V)

18(DC)

Safe overload

(%FS)

150

Ultimate overload
