CPU Support for an Intel® Core™ i7 series processor in the LGA1366 package ( Go to GIGABYTE's website for the latest CPU support list.) L3 cache varies with CPU QPI 4.8GT/s, 6.4GT/s Chipset North Bridge: Intel® X58 Express Chipset South Bridge: Intel® ICH10R Memory 6 x 1.5V DDR3 DIMM sockets supporting up to 24 GB of system memory * Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB. 3/Dual channel memory architecture Support for DDR3 2200/1333/1066/800 MHz memory modules Support for non-ECC memory modules Support for Extreme Memory Profile (XMP) memory modules (Go to GIGABYTE's website for the latest supported memory speeds and memory modules.) Audio 1 x Creative CA20K2 chip Support for Dolby® Digital Live and DTS™ Connect Support for X-Fi Xtreme Fidelity® and EAX® Advanced HD™ 5.0 technologies High Definition Audio 2/4/5.1/7.1-channel Support for S/PDIF Out LAN 1 x Bigfoot Killer E2100 chip (10/100/1000 Mbit) Expansion Slots 2 x PCI Express x16 slots, running at x16 (PCIEX16_1, PCIEX16_2) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16_1 slot; if you are installing two PCI Express graphics cards, it is recommended that you install them in the PCIEX16_1 and PCIEX16_2 slots. 1 x PCI Express x16 slot, running at x8 (PCIEX8) * The PCIEX8 slot shares bandwidth with the PCIEX16_2 slot. The PCIEX16_2 slot will operate at up to x8 mode when the PCIEX8 is populated. (The PCIEX16_1, PCIEX16_2, and PCIEX8 slots conform to PCI Express 2.0 standard.) 2 x PCI Express x1 slots 1 x PCI slot Multi-Graphics Technology Support for 2-Way/3-Way ATI CrossFireX™/NVIDIA SLI technology Storage Interface South Bridge: 6 x SATA 3Gb/s connectors (SATA2_0~SATA2_5) supporting up to 6 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, RAID 5, and RAID 10 Marvell 88SE9182 chip: 2 x SATA 6Gb/s connectors (GSATA3_6, GSATA3_7) supporting up to 2 SATA 6Gb/s devices Support for SATA RAID 0 and RAID 1 JMicron JMB362 chip: 2 x eSATA 3Gb/s connectors (eSATA/USB Combo) on the back panel, supporting up to 2 SATA 3Gb/s devices Support for SATA RAID 0, RAID 1, and JBOD USB South Bridge: Up to 12 USB 2.0/1.1 ports (6 on the back panel, including 2 eSATA/USB Combo, 6 via the USB brackets connected to the internal USB headers) 1 x Renesas D720200 chip and 2 x VLI VL810 hubs: Up to 4 USB 3.0/2.0 ports (2 on the back panel, 2 via the USB bracket connected to the internal USB header) * The USB 2.0 signals of the USB 3.0/2.0 ports on the back panel are from the South Bridge. Internal I/O Connectors 1 x 24-pin ATX main power connecto 1 x 8-pin ATX 12V power connector 2 x SATA 6Gb/s connectors 6 x SATA 3Gb/s connectors 1 x CPU fan header 1 x system fan header 3 x fan headers 1 x front panel header 1 x front panel audio header 1 x S/PDIF Out header 3 x USB 2.0/1.1 headers 1 x USB 3.0/2.0 header 1 x clearing CMOS jumper 1 x heatsink LED power connector Back Panel Connectors 1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x optical S/PDIF Out connector 1 x coaxial S/PDIF Out connector 1 x CPU overclocking button 4 x USB 2.0/1.1 ports 2 x USB 3.0/2.0 ports 2 x eSATA/USB Combo connectors 1 x RJ-45 port 5 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In/Mic In, Line Out) I/O Controller iTE IT8720 chip H/W Monitoring System voltage detection CPU/System temperature detection CPU/System fan speed detection CPU overheating warning CPU/System fan fail warning CPU/System fan speed control * Whether the CPU/system fan speed control function is supported will depend on the CPU/system cooler you install. BIOS 2 x 16 Mbit flash Use of licensed AWARD BIOS Support for DualBIOS ™ PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b Unique Features Support for @BIOS Support for Q-Flash Support for Xpress BIOS Rescue Support for Download Center Support for Xpress Install Support for Xpress Recovery2 Support for EasyTune * Available functions in EasyTune may differ by motherboard model. Support for Dynamic Energy Saver™ 2 Support for Smart 6™ Support for Auto Green Support for eXtreme Hard Drive (X.H.D) Support for ON/OFF Charge Support for Cloud OC Support for Q-Share Bundle Software Norton Internet Security (OEM version) Operating System Support for Microsoft® Windows® 7/Vista/XP Form Factor ATX Form Factor; 30.5cm x 26.4cm Call: 01714-341343 |
